Description

WizSense Series devices integrate Dahua’s cutting-edge Analytics+ with a user-friendly interface. These devices are equipped with industry-leading Smart Motion Detection and Perimeter Protection technologies that concentrate on human and vehicle images, disregarding non-essential visuals to capture critical footage efficiently and reduce false alerts. The WizSense Series offers robust surveillance solutions tailored for small to medium-sized businesses, all at a competitive price point.

System Overview
The X54B5L Series HDCVI DVR delivers 5M-N/1080p recording capabilities across each HDCVI channel, along with a range of advanced features and functionalities. This DVR utilizes HDCVI technology to enable seamless integration into existing video surveillance frameworks, making efficient use of current networks, cabling, and cameras. The Penta-brid access technology facilitates simultaneous recording from HDCVI, AHD, TVI, CVBS, and IP sources, making this recorder a superior choice for active monitoring of public venues, retail environments, transportation hubs, personal properties, and educational facilities.

Functions

General Information
Bandwidth128 Mbps
Brand NameDahua
ManufacturerZhejiang Dahua Technology Co., Ltd.
Manufacturer Part NumberX54B5L
Product LineWizSense
Product Name32-Channel 1.5U Digital Video Recorder with Analytics+
Product SeriesPro
Product TypeVideo Surveillance Station

Interfaces/Ports
Composite Video InYes
Composite Video OutYes
HDMIYes
Number of VGA Out1
Total Number of Audio In Ports4
Total Number of Audio Out Ports1
USBYes

Miscellaneous
Country of OriginCN

Network & Communication
EthernetYes
Remote ManagementYes

Others
ADI Part Number ReplacesVD-X54A5L
Model Number ReplacesX54A5L

Physical Characteristics
Weight (Approximate)10.58 lb

Storage
Hard Drive CapacityNo HDD
Recording Formats4K

Technical Information
Connectivity TechnologyWired
HD RecordingYes
Maximum Frame Rate30 fps
Power Consumption22W
System ComponentsDigital Video Recorder
Total Number of Channels32
Video FormatsH.264, H.265
Video Signal FormatNTSC

Video
Maximum Resolution8MP

Warranty
Limited Warranty5 Year
