Description

Public View Monitors are a crucial component of our business’s Crime Prevention Through Environmental Design (CPTED) approach. These monitors help reduce shrinkage by making potential thieves aware they are being captured on camera, complete with face detection bounding boxes for a strong visual deterrent. They are perfect for retail environments, strategically placed at entrances and display racks. With a built-in, discreet camera, they are easy to install and require only VESA-compliant mounts, eliminating the need for additional accessories. These monitors deliver powerful video performance with crisp image quality, ultra-low light sensitivity, and a wide dynamic range. They can also double as advertising and signage displays, automatically switching from slideshow mode to live view when motion is detected (SD card needed).

Featuring a 10-inch IP public view monitor in a sleek black casing, the 16:9 Full HD LED panel offers a contrast ratio of 500:1 and brightness of 500 NIT with a 20ms response time. The face detection display provides visual deterrence, and customizable text overlays with pre-configured “recording in progress” on-screen displays enhance security. These monitors are VESA mountable (100 x 100mm / 200 x 100mm x 200 x 200mm) and integrate a 2MP IP camera. They offer 1080p HDMI output, a 4.6mm fixed lens with a 73.8-degree horizontal field of view, 150dB Wide Dynamic Range, and support H.265/H.264/MJPEG compression with WiseStream II technology. With micro SD/SDHC/SDXC support, bi-directional audio, and hallway view mode, these monitors are powered via PoE+ or 12V DC, with a 12V DC power supply included.

Audio
Number of Speakers2
SpeakersYes

Camera
Horizontal Viewing Angle140°

Display & Graphics
Backlight TechnologyLED
Color Supported262k
Number of Screens1
Screen ModeWSVGA
Vertical Viewing Angle120°

General Information
Brand NameHanwha Vision
ManufacturerHanwha Group
Manufacturer Part NumberSMT-1030PV
Product ModelSMT-1030PV
Product NameSMT-1030PV Widescreen LCD Monitor
Product TypeLCD Monitor

Aspect Ratio16:9

Interfaces/Ports
HDMIYes
Network (RJ-45)Yes
VGAYes

Miscellaneous
Features3D Comb Filter, Deinterlace Motion, Noise Reduction, On-screen Display (OSD)

Physical Characteristics
ColorBlack
Depth2.6"
Height7.1"
VESA Mount CompatibleYes
VESA Mount Standard75 x 75
Weight (Approximate)4.41 lb
Width9.7"

Product Information
Mount TypeDesktop Mount, Rack Mount, Wall Mount

Technical Information
Response Time20 ms
Screen Size Class10"
Viewable Screen Size10.1"
WebcamYes

Video
Brightness (Nit)500
Maximum Resolution1024 x 600
Native Contrast Ratio500:1
