This Genesis® cable boasts 6 stranded 22 AWG copper conductors, complemented by an overall foil shield with a drain wire, along with a riser rating. Opt for this cable to ensure a reliable connection in security, control systems, audio setups, and various low-voltage applications.
| Certifications | |
| TAA Compliant | Yes |
| General Information | |
| Brand Name | Genesis |
| Manufacturer | Genesis Cable |
| Manufacturer Part Number | 22061101 |
| Packaged Quantity | 1 |
| Product Model | 22061101 |
| Product Name | 22061101 - 22 AWG 6C STR Shielded Riser, White, 1000 FT. Pull Box |
| Product Type | Access & Security Cable |
| Miscellaneous | |
| Environmental Certification | RoHS |
| Environmentally Friendly | Yes |
| Features | Stranded |
| Indoor/Outdoor | Indoor |
| Physical Characteristics | |
| Cable Length | 1000' |
| Color | White |
| Insulation Material | PP |
| Material | Bare Copper |
| Package Type | REELEX Pull Box |
| Weight (Approximate) | 21.40 lb |
| Technical Information | |
| American Wire Gauge | 22AWG |
| Cable Listing | CL3R, CMR, FPLR, FT4, Sunlight Resistant |
| Cable Rating | Riser |
| Cable Type | Multi-conductor/Multi-pair |
| Conductor Count | 3 |
| Conductor Material | Bare Copper |
| Connector on First End | Bare Wire |
| Connector on Second End | Bare Wire |
| Core/Cladding Diameter | 22/6 |
| Device Supported | Security Device |
| Impedance | 59 ohms |
| Jacket Material | PVC |
| Number of Conductors | 6 |
| Number of Pairs | 3 |
| Shielding | Yes |
| Solid or Stranded | Stranded |
| Warranty | |
| Limited Warranty | 3 Year; 3-for-1 |
