Belden 2413 005A1000 CAT6 Plus Plenum Cable, 23/4 Solid BC, Unshielded, UTP, CMP, FT6, 1000′ (304.8m) Reel-in-Box, Green

Name: Belden 2413 005A1000 CAT6 Plus Plenum Cable, 23/4 Solid BC, Unshielded, UTP, CMP, FT6, 1000' (304.8m) Reel-in-Box, Green
Brand: Belden
SKU: 2413 005A1000
Availability: InStock

in stock

Special Order

$549.34

Horizontal Premise Cable optimized for Ethernet standards including 1000BASE-T, 100BASE-TX, and 10BASE-T, plus Power over Ethernet (PoE, PoE+, PoE++) capabilities. Constructed with solid stranding and high-conductivity bare copper conductors.
Comprises 4 twisted pairs.
Comes in a 23 AWG size for enhanced performance.
Designed with solid stranding for durability.
Fabricated from Bare Copper (BC) known for its high conductivity.
Insulated using Polyolefin Fluorinated Ethylene Propylene (PO FEP).
Plenum-rated for safe installation in air return spaces.
Ensures dependable network connectivity.
Incorporates Category 6+ cable specifications to meet modern networking needs efficiently.
Enhanced with PoE++ for improved utility and operational efficiency.

SKU: 2413 005A1000 Categories: Category 6 Network Cables, Network Cables, Wire & Cable Brand: Belden

Description

Enhanced Category 6+ horizontal cable for high-performance network infrastructure, supporting up to 350MHz frequencies. This cable features 4 pairs of 23 AWG solid bare copper conductors and an unshielded twisted pair (U/UTP) design. Engineered for plenum spaces, it includes a Flamarrest® PVC-LS jacket for fire safety and compliance.

General Information
Brand Name	Belden
Manufacturer	Belden CDT, Inc
Manufacturer Part Number	2413 005A 1000
Packaged Quantity	Box
Product Name	Category 6+ Enhanced Cable, 4 Pair, U/UTP, CMP
Product Type	Network Cable

Media & Performance
Data Transfer Rate	1 Gbit/s

Miscellaneous
Environmental Certification	EU RoHS, REACH, RoHS 2
Environmentally Friendly	Yes
Features	Attenuation to Crosstalk Ratio (ACR), Bendable, Equal Level Far End Crosstalk (ELFEXT), Minimized Near-End Crosstalk (NEXT), PoE, PoE+, PoE++, Power Sum Attenuation to Crosstalk Ratio (PSACR), Power-sum Near End Crosstalk (PSNEXT)

Physical Characteristics
Cable Length	1000'
Color	Green
Insulation Material	FEP
Material	Bare Copper, PVC
Package Type	Box, Reel
Product Color	Green, White/Blue, White/Green

Technical Information
American Wire Gauge	23AWG
Cable Listing	CMP, FT6
Cable Rating	Plenum
Cable Type	Category 6+
Conductor Count	4
Conductor Material	Bare Copper
Device Supported	Network Device
Jacket Material	LS FR-PVC
Number of Conductors	8
Number of Pairs	4
Shielding	No
Solid or Stranded	Solid
